Military-Grade Accuracy AI Target Recognition Ground Surveillance Radar
Ⅰ. Product Description
The is an advanced, AI-powered ground surveillance radar system designed for military and high-security applications. Combining Active Digital Phased Array (Azimuth Electronic Scanning) and Pulse Doppler technologies, this radar delivers unparalleled detection and tracking capabilities for personnel, vehicles in real time.
Engineered for border security, military bases, checkpoints, and critical infrastructure protection, the system leverages MIMO architecture and DBF technology to ensure high-resolution target recognition even in challenging environments such as rain, snow, fog, or electronic warfare conditions.
Ⅱ. Product Features
1. Real-Time Monitoring & Rapid Response
Continuously scans surroundings, instantly detecting and alerting on suspicious movements.
AI-powered anomaly detection minimizes false alarms caused by environmental clutter.
2. High-Speed Target Tracking
Tracks objects moving at 1.8 km/h to 108 km/h with stable trajectory updates.
Multi-target tracking for simultaneous monitoring of threats.
3. Wide-Area Coverage & Scalability
Azimuth coverage: ≥90°Elevation coverage: ≥18°
Supports multi-radar networking** for seamless large-area surveillance.
4. All-Weather, All-Terrain Reliability
Operates in extreme temperatures (-40°C to +55°C) and adverse weather (rain, snow, fog).
Low power consumption (≤45 W) for extended field deployment.
5.Easy Deployment
Lightweight (≤5.5 kg) for rapid setup on poles, buildings, or mobile units.
RJ45 Ethernet (100 Mbps) for seamless integration with command centers.
Ⅲ. Product Functions
|
Remote Control
|
Supports remote on/off functionality
|
|
Output Information
|
Capable of obtaining information such as the distance, velocity, and angle of detected objects
|
|
Multi-Target Tracking
|
Supports multi-target tracking switching logic; can track the trajectories of multiple targets in real-time.
|
|
Target Fusion Processing
|
Supports data fusion processing from multiple sensors.Zone Management: Allows flexible setting of zones with precise positioning and the ability to trigger intrusion alarms.
|
|
Zone Management
|
Allows flexible setting of zones with precise positioning and the ability to trigger intrusion alarms.
|
|
Anti-Interference Capability
|
Features online adjustment capabilities for detection sensitivity and speed range, as well as the ability to filter out abnormal trajectory interference. Through sensitivity adjustment and abnormal trajectory filtering functions, it can effectively eliminate false alarms caused by clutter.
|
|
Online Monitoring Function
|
Capable of monitoring working status and issuing fault alarms; also has the ability to alert when the device goes offline.
|
|
Remote Monitoring Status
|
Has remote monitoring capabilities, can report device status in real-time, and features online/offline alarm functions for the device.
|
|
Online Self-Inspection Function
|
The device has the ability to perform online self-inspection.
|
|
Adaptive Processing Capability
|
Has the ability to adaptively handle moving target clutter and adaptively process clutter maps.
|
|
Linkage Function
|
Features radar pan-tilt linkage function, with target tracking and evidence capture (automatic tracking mode, radar tracking mode, image tracking mode).
|
|
Multi-Site Networking and Blanking
|
Capable of networking with multiple devices; has the ability for multi-site collaborative detection; and has the ability to fill in gaps when neighboring sites fail.
|
Ⅳ. Product Parameters
|
Working Mechanism
|
Active Digital Phased Array (Azimuth Electronic Scanning) / Pulse Doppler
|
|
Operating Frequency Band
|
C-band
|
|
Range
|
1.5Km
|
|
Effective Detection Range
|
100 m to 0.8 km (pedestrians)100 m to 1.2 km (small cars)
|
|
Azimuth Coverage
|
≥90°
|
|
Elevation Coverage
|
≥18°
|
|
Detection Speed
|
1.8 km/h to 108 km/h
|
|
Azimuth Accuracy
|
≤1.0°
|
|
Range Accuracy
|
≤8 m
|
|
Data Rate
|
≥2 Hz
|
|
Data Interface
|
RJ45 / 1 × 100 Mbps Ethernet
|
|
Power Input
|
≤45 W (power consumption), AC220V to AC240V (input)
|
|
Operating Temperature
|
-40°C to +55°C
|
|
Weight
|
≤5.5 kg
|
