Multi-Target Recognition & LowPower Consumption Radar Systems Scalable Solutions
Ⅰ. Product Description
The Anti-Drone Radar System represents a breakthrough in UAV detection technology, combining multi-target recognition, low power consumption, and scalable architecture to deliver unparalleled efficiency in safeguarding critical airspace. Designed for military, government, and critical infrastructure protection, this system leverages advanced radar, AI-driven signal processing, and adaptive countermeasures to detect, track, and neutralize multiple drone threats simultaneously—even in clutter-heavy environments.
At its core, the system utilizes phased array radar (5400-5600MHz ISM band) and full-spectrum analysis (20MHz-6GHz) to achieve long-range detection (≥7.5km) with 99% accuracy. Its low-power design (≤100W in detection mode) ensures sustainable operation, while modular components enable flexible deployment—from fixed installations to mobile units.
Whether defending airports, military bases, or public events, the system provides a cost-effective, future-proof solution against evolving drone threats.
Ⅱ. Product Features
1. Multi-Target Recognition & Tracking
Simultaneous tracking of multiple drones targets.
AI-powered classification distinguishes drones from birds, debris, and false signals.
Identification Range: ≥5km (recognizes brands/models).
Detection Range: ≥7.5km(covers database & non-database drones).
2. Low Power Consumption & Energy Efficiency
Detection Mode: ≤100W(optimized for 24/7 operation).
Countermeasure Mode: ≤600W (activates only during threats).
Adaptive power management reduces energy waste.
3. Scalable & Modular Design
Fixed, mobile, or networked deployments.
Quick setup (≤15min) for rapid response.
GIS integration for wide-area coordination.
4. Advanced Countermeasures
Protocol Cracking Decodes LightBridge1/2, OcuSync, WIFI variants.
Deception Takeover GPS-L1 spoofing (adjustable up to 3km).
Jamming Suppression Disrupts control, video, and navigation across:
840-868MHz, 902-928MHz, 2400-2500MHz, 5150-5850MHz.
5. Rugged & Reliable
Operates in -40°C to 55°C (storage: -45°C to 65°C).
IP65-rated for dust/water resistance.
Humidity tolerance: ≤95%.
Ⅲ. Product Functions
|
Functional Indicators
|
Main Performance
|
|
System Detection Configuration
|
Radar Operating Band
|
5400-5600MHz (ISM band exempt from application by International Telecommunication Union)
|
|
Spectrum Detection Band
|
20MHz-6GHz full band
|
|
Operational Range
|
Identification Range: ≥5km (capable of identifying drone brands and models)
|
|
Detection Range: ≥7.5km (detects drones in the database and those using non-database communication protocols)
|
|
Unauthorized Flight Detection Range: ≥2km (detects all drones, including FPV and unauthorized flights)
|
|
Detection Success Rate
|
99%
|
|
Protocol Cracking
|
LightBridge1, LightBridge2; OcuSync; WIFI and WIFI variant protocols
|
|
Deception Takeover
|
Deception Frequency
|
GPS-L1
|
|
Deception Range
|
3km (adjustable)
|
|
Jamming Suppression
|
Jamming Bands
|
840-868MHz(flight control and video transmission)
|
|
902-928MHz(flight control and video transmission)
|
|
1560-1620MHz (navigation)
|
|
2400-2500MHz(flight control and video transmission)
|
|
5150-5850MHz(flight control and video transmission)
|
|
Operational Range
|
1000m
|
Ⅳ. Product Parameters
|
Parameter Indicators
|
|
Dimensions (when deployed)
|
≤1500mm×1500mm×2800mm
|
|
Weight
|
≤25kg (equipment)
|
|
Operating Temperature
|
-40℃～55℃
|
|
Storage Temperature
|
-45℃～65℃
|
|
Protection Rating
|
Ip65
|
|
Operating Humidity
|
≤ 95%
|
|
Data Interface
|
RJ45
|
|
Power Interface
|
Voltage: AC 180V-250V
|
|
Power: ≤100W (detection mode), ≤600W (countermeasure mode)
|
|
Setup Time
|
≤15min
|
|
Packaging
|
2 cases
|
|
Platform Functions
|
Real-time detection, alarm, automatic countermeasures, manual countermeasures, GIS mapping, data storage, event query
|
V. Product Size
