Ⅰ. Product Description
Ground Surveillance Radar is an advanced, high-performance radar system designed for critical border security and infrastructure monitoring applications. This state-of-the-art radar system combines a radar array face with a power adapter unit, utilizing MIMO (Multiple Input Multiple Output) architecture and DBF (Digital Beam Forming) technology to create an active phased array radar solution.
Primarily deployed for border protection, perimeter security, checkpoints, and military base surveillance, this radar system provides comprehensive detection and tracking capabilities for both pedestrian and vehicular movements. The system offers precise target identification by providing accurate positional data including azimuth, distance, and speed information for all detected objects within its coverage area.
The radar's modular design allows for flexible deployment options, enabling installation on existing infrastructure such as light poles or custom-built bases. Multiple units can be networked together to create comprehensive coverage across extended areas.
Ⅱ. Product Features
Real-time Monitoring
provides continuous surveillance of surrounding environments, with immediate detection and response capabilities for any anomalous activities. The system's high refresh rate ensures that security personnel receive the most current information about potential threats.
Enhanced Rapid Target Detection
With exceptional data refresh rates, this radar system maintains stable and consistent tracking of fast-moving targets. The advanced signal processing algorithms enable the system to keep pace with high-speed objects while maintaining tracking accuracy.
Extensive Coverage Area
The radar offers wide-area surveillance capabilities, with the option to network multiple units for expanded coverage. This feature is particularly valuable for creating comprehensive security perimeters around large facilities or along extended border regions.
Simplified Deployment
Designed for practical implementation, the system can be quickly installed using existing infrastructure. The flexible mounting options reduce setup time and costs while maintaining optimal operational effectiveness.
All-Weather, 24/7 Operation
Engineered for continuous operation in all environmental conditions, the radar maintains performance consistency through various weather challenges including precipitation, fog, and other atmospheric disturbances that typically degrade surveillance capabilities.
Adaptive Performance
The system features dynamic adjustment capabilities for detection sensitivity and velocity ranges, ensuring optimal performance across different operational scenarios and environmental conditions.
Ⅲ. Product Functions
|
Remote Control
|
Supports remote on/off functionality
|
|
Output Information
|
Capable of obtaining information such as the distance, velocity, and angle of detected objects
|
|
Multi-Target Tracking
|
Supports multi-target tracking switching logic; can track the trajectories of multiple targets in real-time.
|
|
Target Fusion Processing
|
Supports data fusion processing from multiple sensors.Zone Management: Allows flexible setting of zones with precise positioning and the ability to trigger intrusion alarms.
|
|
Zone Management
|
Allows flexible setting of zones with precise positioning and the ability to trigger intrusion alarms.
|
|
Anti-Interference Capability
|
Features online adjustment capabilities for detection sensitivity and speed range, as well as the ability to filter out abnormal trajectory interference. Through sensitivity adjustment and abnormal trajectory filtering functions, it can effectively eliminate false alarms caused by clutter.
|
|
Online Monitoring Function
|
Capable of monitoring working status and issuing fault alarms; also has the ability to alert when the device goes offline.
|
|
Remote Monitoring Status
|
Has remote monitoring capabilities, can report device status in real-time, and features online/offline alarm functions for the device.
|
|
Online Self-Inspection Function
|
The device has the ability to perform online self-inspection.
|
|
Adaptive Processing Capability
|
Has the ability to adaptively handle moving target clutter and adaptively process clutter maps.
|
|
Linkage Function
|
Features radar pan-tilt linkage function, with target tracking and evidence capture (automatic tracking mode, radar tracking mode, image tracking mode).
|
|
Multi-Site Networking and Blanking
|
Capable of networking with multiple devices; has the ability for multi-site collaborative detection; and has the ability to fill in gaps when neighboring sites fail.
|
Ⅳ. Product Specifications
|
Working Mechanism
|
Active Digital Phased Array (Azimuth Electronic Scanning) / Pulse Doppler
|
|
Operating Frequency Band
|
C-band
|
|
Range
|
100 m to 0.8 km (pedestrians)
|
|
Effective Detection Range
|
100 m to 0.8 km (pedestrians)100 m to 1.2 km (small cars)
|
|
Azimuth Coverage
|
≥90°
|
|
Elevation Coverage
|
≥18°
|
|
Detection Speed
|
1.8 km/h to 108 km/h
|
|
Azimuth Accuracy
|
≤1.0°
|
|
Range Accuracy
|
≤8 m
|
|
Data Rate
|
≥2 Hz
|
|
Data Interface
|
RJ45 / 1 × 100 Mbps Ethernet
|
|
Power Input
|
≤45 W (power consumption), AC220V to AC240V (input)
|
|
Operating Temperature
|
-40°C to +55°C
|
|
Weight
|
≤5.5 kg
|
