Long Range Scanning & Clutter Filtering Radar Systems Performance in All Weather
Ⅰ. Product Description
In an era where drone threats are evolving rapidly, the Anti-Drone Radar System stands as a cutting-edge solution for long-range detection, precision tracking, and effective neutralization of unauthorized UAVs. Designed to operate in all weather conditions, this system integrates advanced radar technology, AI-powered clutter filtering, and multi-spectrum jamming to deliver unmatched performance in protecting critical infrastructure, military installations, and public spaces.
The system’s phased array radar enables rapid, wide-area scanning with exceptional accuracy, distinguishing drones from birds, debris, and other false targets. Its adaptive signal processingensures high detection rates even in clutter-heavy environments (urban areas, forests, or adverse weather). Combined with full-spectrum analysis (20MHz-6GHz) and GPS spoofing capabilities, the system provides a comprehensive, multi-layered defense against both commercial and malicious drones.
Whether deployed as a fixed installation or mobile unit, this system is engineered for harsh environments (-40°C to 55°C) and offers quick setup (≤15min), making it ideal for rapid-response scenarios.
Ⅱ. Product Features
1. Advanced Radar with Long-Range Scanning
Detection Range: ≥7.5km(covers database & non-database drones).
Identification Range: ≥5km(recognizes drone brands & models).
Unauthorized Flight Detection≥2km(including FPV & rogue drones).
5400-5600MHz ISM band (ITU-compliant, interference-free operation).
2. Superior Clutter Filtering & AI-Powered Tracking
Adaptive Doppler filtering eliminates ground/weather clutter.
AI-based classification distinguishes drones from birds/debris.
99% detection success rate industry-leading reliability.
3. All-Weather Performance
Operates in -40°C to 55°C (storage up to -45°C to 65°C).
IP65-rated—resistant to rain, dust, and extreme conditions.
Humidity tolerance: ≤95% (suitable for coastal/tropical regions).
4. Multi-Layered Countermeasures
Protocol Cracking Decodes LightBridge1/2, OcuSync, WIFI & variants.
Deception Takeover GPS-L1 spoofing (adjustable up to 3km).
Jamming Suppression Disrupts control, video, and navigation signals across:
840-868MHz, 902-928MHz, 2400-2500MHz, 5150-5850MHz.
5. Modular & Rapid Deployment
≤15min setup time—ideal for emergency responses.
Modular design supports fixed, mobile, or networked deployments.
GIS integration for real-time threat mapping.
Ⅲ. Product Functions
|
Functional Indicators
|
Main Performance
|
|
System Detection Configuration
|
Radar Operating Band
|
5400-5600MHz (ISM band exempt from application by International Telecommunication Union)
|
|
Spectrum Detection Band
|
20MHz-6GHz full band
|
|
Operational Range
|
Identification Range: ≥5km (capable of identifying drone brands and models)
|
|
Detection Range: ≥7.5km (detects drones in the database and those using non-database communication protocols)
|
|
Unauthorized Flight Detection Range: ≥2km (detects all drones, including FPV and unauthorized flights)
|
|
Detection Success Rate
|
99%
|
|
Protocol Cracking
|
LightBridge1, LightBridge2; OcuSync; WIFI and WIFI variant protocols
|
|
Deception Takeover
|
Deception Frequency
|
GPS-L1
|
|
Deception Range
|
3km (adjustable)
|
|
Jamming Suppression
|
Jamming Bands
|
840-868MHz(flight control and video transmission)
|
|
902-928MHz(flight control and video transmission)
|
|
1560-1620MHz (navigation)
|
|
2400-2500MHz(flight control and video transmission)
|
|
5150-5850MHz(flight control and video transmission)
|
|
Operational Range
|
1000m
|
Ⅳ. Product Parameters
|
Parameter Indicators
|
|
Dimensions (when deployed)
|
≤1500mm×1500mm×2800mm
|
|
Weight
|
≤25kg (equipment)
|
|
Operating Temperature
|
-40℃～55℃
|
|
Storage Temperature
|
-45℃～65℃
|
|
Protection Rating
|
Ip65
|
|
Operating Humidity
|
≤ 95%
|
|
Data Interface
|
RJ45
|
|
Power Interface
|
Voltage: AC 180V-250V
|
|
Power: ≤100W (detection mode), ≤600W (countermeasure mode)
|
|
Setup Time
|
≤15min
|
|
Packaging
|
2 cases
|
|
Platform Functions
|
Real-time detection, alarm, automatic countermeasures, manual countermeasures, GIS mapping, data storage, event query
|
